Rawrr Mantis Mini R: Start Your Adventure Here.
Choose the perfect fit with the Mantis Mini R and Mantis Mini R17, designed for different rider heights and riding needs.
Model Specifications:
-
Mantis Mini R
- Tire Size: 14" front | 12" rear
- Ideal Rider Height: 3.5' - 4.25'
-
Mantis Mini R17
- Tire Size: 17" front | 14" rear
- Ideal Rider Height: 4' - 5.6'
Both models offer post-purchase upgrade or downsizing options, ensuring long-term adaptability as riders grow.
72V Mantis Mini R/R17 Owners Manual - Updated March 26, 2025.
Tech Specs:
Measurements
|
Length 158cm |
Height 96cm |
|
Width 67cm |
Max Clearance 24cm |
|
Wheelbase 107cm |
Seat Height 73cm |
|
Front Tire Size 60/100-14 |
Rear Tire Size 2.75/12 |
|
Front Brake Rotor Size 203mm |
Rear Brake Rotor Size 203mm |
|
Vehicle Weight With Battery 49kgs |
Max Payload 75kgs |
Performance & Safety
|
Top Speed 75kph |
Acceleration 0-75 KPH 3.6s |
|
Range 50kms |
Max Torque 154.9 Ft Lbs |
|
Max Motor Power 4500W |
Regular Motor Power 2000W |
|
App Controlled Tuning Yes |
Kill Switch Yes |
|
Chain Cover Yes |
Kickstand Sensor Yes |
|
Break Sensors Yes |
Top Speed Limiter Yes |
Care Instructions
Care Instructions
Washing Instructions:
While the Mantis X Pro is water resistant, we do not recommend spraying water in certain areas. Specifically avoid spraying water at the controls on the handlebar and at the area around the charging port.
Where to Avoid:
Avoid spraying water at the dash, throttle, handlebar controls and charging port areas. Instead, use a damp cloth to clean off these areas.
Where you can spray water:
You can spray water at or below the fender in the front, the frame below the seat, swing arm, rear wheel, rear suspension, and rear fender.
Maintenance:
Make sure to change your gear oil at regular intervals. Refer to your user manual or our service & support page for instructions and information on servicing your Mantis.
